Pulsed Magnetron MI-723 for Industrial Applications and Frequency Control

Microwave Tubes & Amplifiers

Manufacturer: PLUTON OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Magnetrons MI-723 pulse action, packetised, partially magnetically shielded design, 2-mm wavelength range, with mechanical or electronic frequency tuning 138000 100MHz with output pulse power of not less than 800 W, designed for use in equipment of national and economic purpose.Magnetrons MI-723, unlike conventional magnetrons they have 2 outputs - one "active" and one "reactive". In this case, the main power for external devices is transferred to the "active" pin, and to the "reactive" pin can be connected to various passive devices to improve the output characteristics of the generator.

Specifications

Filament voltage

6.6 V

Filament current

2 A

Center frequency of the operating frequency range

138000

Weight

1.5 kg

Dimensions, DxWxH

75x80x120 mm

Gamma percent MTBF

500

Anode current

6.5...7.5 A

Anode voltage

9 kV

Output pulse power

0.8 kW

Operating frequency range

137.35...138.65
