Signal Transformer Modules MTS1 for Continuous Signal Transmission in Data Systems
Manufacturer:
PJSC "MSTATOR"
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
Modules transformer signal MTS1 are designed for transmission of continuous signals in interface channels of data and information transmission systems in accordance with IEEE 802.3 standard with operating frequency range up to 100 MHz. Quality category "VP".
Specifications
Resistance of windings to direct current, not more
1.3 ohm
In-phase noise suppression (5 MHz), not less
-50
In-phase interference suppression (100 MHz), not less than
-27,9
Transformer turns ratio
1:1
Electrical strength of insulation between input and output windings: AC test voltage (time of exposure)
1650 V
Insulation resistance between input and output windings (voltage 100 V), not less than
500 (×10^6) ohm
Primary winding inductance (100 kHz, 0,1 V), not less than
440 (×10^-6)
Operating temperature range
-60...105 °C
Primary winding inductance (100 kHz, 0.1 V, 8 mA), not less than
350 (×10^-6)
Winding scattering inductance (100 kHz,0,1 V)
0,3(×10^-6)
Operating signal attenuation (1-100MHz), not more than
-1
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
