Two-Stage Worm Gear Motor-Reducer DRV for Flexible Installation

Double-stage worm gearmotors of DRV series are characterised by a modernized The DRV series worm gearmotors are characterised by a modernised, universal housing that allows the gear unit to be mounted in any position. Gearbox is manufactured using injection moulding technology. Thanks to its simple and robust Thanks to its simple and robust design, it offers high performance and quiet operation.

It is used in electric drives requiring low rotational speed with high torque. Model: DRV Size: 30/40 - 30/50 - 30/63 - 40/75 - 40/90 - 50/110 - 50/130 Gear ratio: "i" = 300:1 - 3200:1 Power: 0.06 - 1.5 kW Torque: 68 - 2150 Nm Unit designation DRV - 040/075 - 3000 - 0.5 - 0.06 B5 - AS1 , where DRV is a worm gearmotor with two stages; 040/075 - combination of 040 and 075 size gearboxes; 3000 - gear ratio; 0,5 - output shaft speed (rpm); 0,06 - motor power (kW); B5 - type of flange; AS1 - mounting position.
