Available for Import

Belt Grinding Machine SGC-100 for Centerless Grinding and Polishing

Metal Grinding Machines

Manufacturer: SK "HOKHMAN" LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

SGC-100 belt grinding machine is designed for centreless grinding and polishing of round workpieces with diameter from 10 to 205 mm and length from 300 mm in coolant environment. The workpiece material can be aluminium and its alloys, non-ferrous metals based on copper, ferrous steels, stainless steels and other materials subjected to grinding with endless grinding belts. Surface roughness is achieved by using belts with different grits as well as Scotch-Brite polishing belts of all types. To achieve a mirror-like surface, it is necessary to use an abrasive-free belt with a polishing paste of the required grit. Since grinding takes place in a coolant environment, the belt material and workpiece must allow working in a coolant environment. The body and main parts of the machine are made of steel and painted with high quality paint, which provides protection against environmental influences.

Specifications

Machine type

cylindrical grinding

Materials to be processed

Aluminum, copper, steel

Power

6.3 kW

Type of product according to PP RF 616

Grinding, polishing, finishing machines

Height

2100 mm

Width

1100 mm

Length

1700 mm

Endless belt size, width

100 mm

Endless belt size, length

3000 mm

Belt speed (adjustable)

5...30

Diameter of the workpiece to be machined

10...205 mm

Minimum workpiece length

300 mm

Maximum workpiece weight

300 kg

Minimum/maximum amount of coolant in the tank

100 l

Machine weight (dry)

550 kg

Machine weight (filled)

650 kg

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
