Disc Harrow BDM 4x2PU - Heavy-Duty Towed Model Available for Import

Disc Harrow BDM 4x2PU - Enhance Your Soil Preparation Efficiency

Disc Harrows
Manufacturer: VYATKA-AGRODIZEL LLC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

Trailed disc harrow BDM 4x2PU The main difference from (just a trailed harrow) is that it is reinforced with an additional frame over the harrow, as well as there is a set of folding. It is designed for use in soil and climatic conditions with soil moisture up to 40%, as well as on fields with a large amount of crop residues. Each disc of the trailed modular disc harrow BDM 4X2P is mounted on an individual stand, which allows the harrow to work on fields with a large amount of crop residues and weeds, eliminating the winding of crop residues on the disc axle and clogging of the inter-disc space, as well as provides high maintainability of the machine. The trailed disc harrow BDM 4x2P provides smooth adjustment of the angle of attack of each disc row within the range from 0 to 30 degrees, which allows for optimal adjustment of the BDM 4X2P harrow for different types of soils.

Specifications

Type of product according to PP RF 616
Disc harrows
Capacity per hour
4.3
Operating speed
15
Length
4250 mm
Width
5000 mm
Height
1422 mm
Working width
4.3 m
Harrow type
semi-trailer
Distance between rows
1150 mm
Weight
2200 kg
Number of implement rows
2 pcs
Material of working elements
steel 65
Material of frame structures
09 g 2s steel
Number of working orans
38 pcs

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
