Disc Harrow BDM-8x4P for Effective Soil Tillage and Preparation

Disc harrow. Semi-trailed disc tillage implement. It consists of: three welded frames (central frame, two wings) with welded sleeves, in which the working elements are installed with the possibility of rotation at a limited angle.

The working element (cutting unit) is a rigid column, a bearing unit and a spherical disc, which is the direct working element that cultivates the soil; truss, which is a welded structure to which the centre frame, wing lift hydraulic cylinders, undercarriage, trailed implement are attached; trailer hitch; hydroficated chassis. The implement has four rows of working tools. For levelling the cultivated soil, a leveller (roller) is hinged to the frame from behind.

The implement can be equipped with the following types of rollers: tubular, spiral or chevron rollers. The roller can be used to adjust the working depth. The width of the cultivated strip is 8m.
