Fume Extraction Cabinet for Muffle Furnaces SHVM-2 - Efficient Air Quality Control

The frame of the support cabinet is made of rectangular steel pipe with cross-section 50x25mm, painted with powder paint with shagreen leather texture, colour RAL7035 (light grey) or RAL 9006 (white). Worktop: porcelain stoneware (ceramic tiles 300x300mm). Side and back panels are faced with a row of ceramic tiles to a height of 300mm.

Body - 16mm thick chipboard. Lifting screen with the possibility of fixing at any height - armoured glass 5 mm thick, lifting 0-750mm, increases the height of the cabinet at full lifting by 430mm. Counterweights are located on the rear panel.

2 levels of extraction. Dustproof (IP65) luminaire for 40-60W incandescent bulbs. Service panel - laminated MDF: switch, circuit breaker 16A, two splash-proof sockets with cover (IP20 3,2kW), wiring box (IP55), located on the back side.

Flange d=100mm (distance from the back panel to the centre of the flange is 140mm). The cabinet is mounted on adjustable supports.
