LED Lighting Power Supply Unit PR-IP-200-105R-286-M-67-01 for Reliable Illumination

Power Supply Parts

Manufacturer: PRANKOR LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

1.Basic information about the product 1.1 Power supplies for LED lighting fixtures (hereinafter referred to as IP), designed for use as a secondary power supply for LED lighting fixtures. 1.2 The power supplies are designed for operation in the AC network with nominal voltage 220±20% V, frequency 50 Hz. 1.3.??

corresponds to the I class of protection against electric shock according to GOST R IEC60598-1-2011, in terms of the impact of mechanical factors of the environment - group of operating conditions M1 according to GOST 17516.1. 1.4.Type of climatic execution - UHL, category 1 according to GOST 15150-69. The products are designed for operation in areas with temperate and cold climate.

Specifications

Weight

1000 year

Overall dimensions (L*W*H)

200...60 mm

Galvanic isolation

Got it

Humidity

20...95 %

Operating temperature range

40...60 °C

Dimming

Check. 0 - 10V, PWM

Output current adjustment range

0.11...1.05 A

Output voltage range

143...286 V

Ground leakage current

<1 mA

Power factor

>0.95

Active power corrector

Got it

Frequency of supply voltage

47...63

AC supply voltage

100...277 V

Efficiency

93 %

Rated power

200 W

Type of product according to PP RF 616

Lighting fixtures and lighting fittings other than those included in other groupings

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
