Multi-stranded Insulated Cables KPLM-OS for Temperature Ranges

Available for Import

Multi-stranded Insulated Cables KPLM-OS for High Temperature Applications

On-Board Electrical Wires

Manufacturer:Podolsk Cable OJSC

Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

On-board KPLM cables Cables on-board KPLMU

Description

Cables multicore with polyethylene insulation braided, small-sized are designed for operation at temperatures from minus 60 to +85 °? and voltage up to 250 V AC frequency up to 5000 Hz or 350 V DC. Service life is not less than 15 years at operation in the temperature range from minus 60 to +85 ° C.

Specifications

Core material

tinned copper stranded

Insulation material

polyethylene

Cladding

Capron sheath

Winding

Polyamide film (wrapping with polyamide film and braiding with lavsan threads over single-pair cables of KPLEMU grades is not provided).

Protective cover

braiding of lavsan yarns impregnated with organosilicon varnish

Section

0.12 to 1.50 mm²

Number of cores

4 to 52

Nominal voltage

250 ?

Climatic version

In accordance with GOST 15150-69

Execution

Quality category - OS
