Power Cable K9RV with Copper Conductor and EPR Insulation Available for Import

Power Cable K9RV with Copper Conductor and EPR Insulation for Electrical Energy Distribution

Copper Power Cables 1kV
Manufacturer: UGLICHKABEL LLC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

Power cable with insulation made of high-modular ethylene propylene rubber, designed for transmission and distribution of electrical energy in stationary installations for rated alternating voltage of 0,6/1 rated frequency up to 50 Hz. The cable is manufactured for general industrial application and is intended for stationary laying in the air, in enclosed spaces, in the ground, in cable collectors for single laying, including in explosive zones when supplied to the domestic market and for export, including countries with tropical climate. Types of climatic execution of cables - UHL, XL and T.

Specifications

Rated AC voltage
1 kV
Material of conductive cores
Copper
Insulation material of conductive cores
High modulus ethylene propylene rubber (HEPR)
Availability of reservations
no
Armor type
not applicable
Outer sheath material (if no armor)
Polyethylene (PE / PE)
Material of protective hose (if armor is available)
Polyethylene (PE / PE)
Availability of metal screen
Yes; no
Fire hazard class
?2.8.2.5.4
Cable cross-sectional shape
Round
Design of conductor core(s)
Single-wire round (ok); multiwire round (mc); multiwire sector (ms)
Nominal cross-section of conductive cores
1000 mm²
Number of conductive cores
1...5
Nominal cross-section of conductive cores
240 mm²
Mark
K9RVP; K9RVEP; K9RVAPu; K9RVEPu; K9RVEPu
Cable shape
Round
Core material
Copper
Insulation material
High modulus ethylene propylene rubber (HEPR)
Sheath material
Polyethylene (PE / PE)

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
