Power Take-Off Box for Special Vehicles 85.503-4202010-30 - Efficient Power Transfer

The power take-off box (PTO) 85.503-4202010-30 is designed to drive units of the special vehicle. It is installed on the right side hatch gearbox chassis Ural and MAZ vehicles with a YAMZ engine flange forward.KOM drive - from the gear of power take-off secondary shaft gearbox.KOM type - mechanical with a mechanism for switching on the power take-off, acting from the pressure of compressed air pneumatic system of the vehicle chassis. KOM is designed to drive the units of the special vehicle by means of a cardan shaft.

This box can be used at ambient air temperature from minus 45 to plus 50 degrees C, relative humidity up to 98% at a temperature of plus 25 degrees C, wind speed up to 20 m/s, intensity of precipitation 5 mm/min, air dustiness up to 1.5 g/m.
