R50 Type 1/5 Turnout for Metro Railways - Enhancing Track Switching Efficiency

The track crossing type ?50 of 1/5 grade on reinforced concrete bars with screw and dowel fastening is designed for laying on the railway tracks of the underground. It is intended for transfer of rolling stock from one track to another. The crossbar is solid cast. The counter rail is not connected with the track rail. The shackles and frame rails are hardened by HFI.
