R65 Switch Type Rail Turnout Model 1/11 for Efficient Track Switching
Manufacturer:
NSZ OJSC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Available Models
Description
Designed for the transfer of rolling stock from one track to another. It is used on the tracks of railway lines with mixed cargo-passenger train traffic and speeds of passenger trains on the straight track up to 140 km/hour. Design features: translations: on crutch and terminal fastening; switches: rotary shackles, frame rails and shackles are hardened on HFI units, pads with cushions on riveted connection; crosses: prefabricated with rail usoviki and cast core of high-manganese steel with liner and overlay end of the rear outreach, counter rail from angle SP850.
Specifications
Cross type by angle
Spicy
View
Single
Type of single transfer
Ordinary
Arrow design
With rotating sharps
Cross brand
1/11
Rail type
?65
View in the direction of a side or crossing track
Left
Cross type by construction
Team
Type of product according to PP RF 616
Track equipment and devices and their parts
Type of timber
wooden
