Smooth Entry Collectors for Air-Cooled Systems (GAC Type)

1. Soft-entry manifolds are designed for installation in air-cooling units (AHUs) and serve the purpose of creating air flow direction.

1.1 Composition of the soft inlet manifold The manifold consists of fibreglass sections fixed between each other and with the air cooling unit (ACU) by bolted connections. The sections are manufactured by injection moulding with thermal polymerisation. The design of sections provides their high strength and rigidity at low weight.

1.2 Technical characteristics of soft inlet manifolds Soft inlet manifolds are manufactured in diameters from 0.4m to 10.0m. The height of smooth inlet manifolds is from 0.3m to 0.7m.
