Special Grain Transport Truck 4594U1 on Ural 73945-01 Chassis

Available for Import

Special Grain Transport Truck 4594U1 for Bulk Cargo Transport

Diesel Cargo Trucks

Manufacturer:MEGATRON LLC

Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

A special truck for the transport of grain, designed for the transport of bulk goods of national economy and agricultural products (grain, seeds, except flax and rape). The superstructure is equipped with ties and turnbuckles, which additionally strengthens the strength of the structure. In the places of opening and closing of the sides there are slats with a seal.

Specifications

Technically permissible weight

21000...26500 kg

Wheel arrangement

6?4

Gross vehicle weight

9000...17000 kg

Payload

13500...14085 kg

Body volume

Internal dimensions of the body

5500x2420x1700

Base chassis

URAL73945-01

Wheelbase

4905+1440

Side panel design

Platform sides articulated of two sides. The upper board is fixed, rigidly fixed to the struts and platform hull. Lower board is movable with upper linkage, hinged to the lower edge of the upper fixed board. The height of the lower board is 850mm.

Design of front and rear sides

Front side - fixed, on the driver's side there are fixed brackets (inside and outside) for easy access to the body. The rear wall can be executed in four variants: a)upper 300 mm high with lower hinged hinged under the grain bin, middle and lower not

Superstructure material

Superstructure material steel 09G2S and 08PS. Thickness of side panels 1,5...2mm, floor decking 3mm.

locking mechanism

Side locks are mechanical, manually opened.

Additional option

Installation of Doser (on the rear side for batch unloading) Installation of awning, frame with winding device + service platform. Installation of canopy with anti-propulsion arches. Service platform for awning-frame (canopy). Installation of overhead

Type of product according to PP RF 616

Trucks

Type of product according to PP RF No. 616

Motor vehicles for cargo

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
