Thermodynamic Cycles of Piston Machines Laboratory Setup for Educational Purposes

Laboratory stand "Thermodynamic cycles of reciprocating machines" provides laboratory and practical classes in institutions of primary vocational, secondary vocational and higher vocational education, to study the design and principle of operation of the reciprocating compressor, as well as thermodynamic processes in reciprocating machines. Technical characteristics Dimensions: Length - 1600 mm; Width - 700 mm; Height - 1600 mm. Power supply from AC mains: Voltage 380V, frequency 50Hz.

Composition of the stand. The laboratory table consists of a base, which is a welded structure made of a metal profile covered with powder paint. The base is mounted on anti-vibration legs.

Complete set

1. laboratory installation "Thermodynamic cycles of piston machines" assembled - 1 pc.
2. Training video, methodical instructions, operating manual - 1 pc.
3. Warranty card - 1 pc.
4. Passport - 1 pc.
