Wireless Single Output Module for Fire Alarm Control - ARG-WL8-OUT

Block executive radio channel IB-PRO is designed to control fire automation devices as part of the system "Strelets-Integral". IB-PRO has a relay output. Relay output parameters: - maximum switching voltage - 30 V DC, 250 V AC; - maximum switching current - 7 A.

The IB-PRO can control the line to the load, the line to the power supply, by which this load is activated and (when controlling smoke or fire dampers) the position of the damper flap. The type of communication line to the daughter devices is wireless. Operating frequency range MHz 868.Maximum radiated power mW 25.External fault input (FLT).

Main and backup power supply: type CR123A voltage V 3, capacity A.h 1,2.Degree of protection of the shell IP 41.Overall dimensions mm 210h143h 38. Weight kg 0,3.Operating temperature range °? -30...+55..
