نظام البرمجيات والأجهزة المعقدة للحفر التلقائي لتحسين أتمتة عمليات الحفر
الشركة المصنعة:
DIGITAL DRILLING LLC
السعر:
طلب عرض سعر
أسعار الجملة متاحة
شروط FOB و CIF و EXW متاحة
الوصف
هذا measurement and control devices مصنوع في روسيا ومتاح للاستيراد إلى الأسواق العالمية. المنتجات الروسية معروفة بمتانتها وموثوقيتها ونسبة السعر إلى الأداء الممتازة.
للحصول على مواصفات المنتج التفصيلية، يرجى الاطلاع على علامة تبويب المواصفات. اتصل بفريقنا لطلب معلومات الأسعار والتوافر والشحن.
المواصفات
Overall dimensions (HxWxG) for AKB-SHU-01/AKB-SHU-02, mm
800x600x250
Average service life for AKB-SHU-01/AKB-SHU-02, not less
7 year
Average MTBF including maintenance for AKB-SHU-01/AKB-SHU-02
30000
Personal protection class against electric shock for AKB-SHU-01/AKB-SHU-02
0I
Ambient storage humidity limit for AKB-SHU-01/AKB-SHU-02, %
98 (at + 25 degrees Celsius)
Storage temperature limit for AKB-SHU-01/AKB-SHU-02, degree Celsius
From - 60 to + 50
Group of conformity to the conditions of transport and storage for AKB-SHU-01/AKB-SHU-02
3
Maximum relative humidity of environment for AKB-SHU-01/AKB-SHU-02, %
98 (at + 25 degrees Celsius)
Operating ambient temperature limit for AKB-SHU-01/AKB-SHU-02, degrees Celsius
From - 60 to + 40
Category of accommodation by climatic execution for AKB-SHU-01/AKB-SHU-02
UHL2
Degree of protection against environmental influences for AKB-SHU-01/AKB-SHU-02
IP65
Insulation resistance between mains leads and grounding screw for AKB-SHU-01/AKB-SHU-02, not less, MOhm
20
Rated insulation voltage (AC) for AKB-SHU-01/AKB-SHU-02
750 V
Rated main circuit current for AKB-SHU-01/AKB-SHU-02, A
20/10
Rated frequency of AC mains for AKB-SHU-01/AKB-SHU-02
SBVVBG
Rated supply voltage for AKB-SHU-01/AKB-SHU-02, V
220 +/- 20 %
Overall dimensions (HxWxG) for AKB-SS, mm
300x300x150
Average service life for the SHS battery, not less
7 year
Average MTBF including maintenance for the SHS battery 523704:Average MTBF including maintenance for the SHS battery
30000
Protection class of a person against electric shock for AKB-ShS
0I
Maximum ambient humidity during storage for AKB-SS, %
98 (at + 25 degrees Celsius)
Limit storage temperature for AKB-SS, degree Celsius
From - 60 to + 50
Group of conformity to the conditions of transport and storage for AKB-SS
3
Maximum relative humidity of the environment for AKB-SS, %
98 (at + 25 degrees Celsius)
Limit ambient operating temperature for AKB-SS, degree Celsius
From - 60 to + 40
Category of placement according to climatic version for AKB-SS
UHL2
Degree of protection against environmental influences for AKB-SS
IP65
Insulation resistance between mains leads and grounding screw for AKB-SS, not less, MOhm
20
Rated insulation voltage (AC) for AKB-SS
750 V
Rated main circuit current for AKB-SS
6 A
Nominal supply voltage (AC) for the SS-Battery packs
220 V
Overall dimensions (HxWxG) for AKB-SHA, mm
600x400x200
Average service life for AKB-SHA, not less
7 year
Average MTBF including maintenance for Batteries-SA
30000
Personal protection class against electric shock for AKB-SHA
0I
Maximum ambient humidity during storage for AKB-SHA, %
98 (at + 25 degrees Celsius)
Storage temperature limit for AKB-SHA, degree Celsius
From - 60 to + 50
Group of conformity to the conditions of transport and storage for AKB-SA
3
Maximum relative humidity of the environment for AKB-SHA, %
98 (at + 25 degrees Celsius)
Limit ambient operating temperature for AKB-SHA, degree Celsius
From - 60 to + 40
Category of placement according to climatic version for AKB-SHA
UHL2
Degree of protection against environmental influences for AKB-SHA
IP65
Insulation resistance between mains terminals and grounding screw for AKB-USA, not less, MOhm
20
Rated isolation voltage (AC) for battery-USA
750 V
Rated current of main circuit for BKB-SA
16 A
Rated frequency of the AC mains network for AC-Battery-USA
SBVVBG
Rated supply voltage for ACB-SHA, V
220 +/- 20 %
Overall dimensions (HxWxG) for AKB-OBK, mm
600x400x200
Average service life for Batteries-OBK, not less than
7 year
Average MTBF including maintenance for Battery-OSBs
30000
Personal protection class against electric shock for AKB-OBK
0I
Maximum ambient humidity during storage for AKB-OBK, %
98 (at + 25 degrees Celsius)
Limit storage temperature for ABB-OBK, degree Celsius
From - 60 to + 50
Group of conformity to the conditions of transport and storage for Batteries-OBK
3
Maximum relative humidity of the environment for AKB-OBK, %
98 (at + 25 degrees Celsius)
Operating ambient temperature limit for AKB-OBK, degree Celsius
From - 60 to + 40
Category of placement according to climatic version for AKB-OBK
UHL2
Degree of enclosure protection against environmental influences for AKB-OBK
IP65
Insulation resistance between mains leads and grounding screw for BAC-OBK, not less, MOhm
20
Rated isolation voltage (AC) for ABB-OBKs
750 V
Rated main circuit current for AKB-OBC
10 A
Rated frequency of AC mains for AC-BB-OBK
SBVVBG
Rated supply voltage for battery-OBK, V
220 +/- 20 %
Overall dimensions (HxWxG) for Batteries-VSP, mm
433x333x224
Average service life for ACB-VSP, not less
7 year
Average MTBF including maintenance for Battery-BL
30000
Personal protection class against electric shock for AKB-VSP
0I
Maximum ambient humidity during storage for AKB-VSP, %
98 (at + 25 degrees Celsius)
Limit storage temperature for VSP batteries, degrees Celsius
From - 60 to + 50
Group of conformity to the conditions of transportation and storage for ACB-VSP
3
Ambient relative humidity limit for ACB-VSP, %
98 (at + 25 degrees Celsius)
Limit temperature of the operating environment for VSP-Battery, degree Celsius
From - 60 to + 40
Category of placement according to climatic design for AKB-VSP
UHL2
Degree of enclosure protection against environmental influences for ACB-VSP
IP65
Type of explosion protection (enclosure design when located in hazardous areas) for Batteries-VSP
1Ex d IIC T6 Gb X
Insulation resistance between mains leads and grounding screw for battery-VSP, not less, MOhm
20
Rated insulation voltage (AC) for ACB-VSBs
750 V
Rated main circuit current for ACB-VSP
6 A
Nominal supply voltage (AC) for ACB-VSBs
220 V
Overall dimensions (HxWxG) for AKB-BL, mm
400x400x200
Average service life for AKB-BL, at least
7 year
Protection class of a person against electric shock for AKB-BL
0I
Limit ambient humidity during storage for AKB-BL, %
98 (at + 25 degrees Celsius)
Operating ambient temperature limit for ACB-BL, degree Celsius
From - 60 to + 40
Storage temperature limit for AKB-BL, degrees Celsius
From - 60 to + 50
Group of conformity to transport and storage conditions for AKB-BL
3
Ambient relative humidity limit for BKB-BL, %
98 (at + 25 degrees Celsius)
Category of placement according to climatic version for AKB-BL
UHL2
Degree of protection of the enclosure against environmental impact for AKB-BL
IP65
Insulation resistance between mains leads and grounding screw for BKB-BL, not less than, MOhm
20
Rated isolation voltage (AC) for AC-BLs
750 V
Rated main circuit current for ACB-BLs
6 A
Rated frequency of the AC mains for ACB-BLs
SBVVBG
Rated supply voltage for Battery-BL, V
220 +/- 20 %
