Automatic calibration of the micromotor system
Got it
Apical Reverse function
apical reversal when apex point is reached
Apical Slow Down function
automatic motor slowdown when approaching apex
Weight of the Estus Smart-B smart apex locator stand
80 year
Overall dimensions of Estus Smart-B smart stand-apexlocker
(100*60*40) ±3 mm
Estus Smart-B battery full charge time
270
Estus Smart-B continuous operation time with a new fully charged battery without recharging it
65
Measuring range of external apex-locator in Estus Smart-B smart cradle
3...0 mm
Display parameters of Estus Smart-B smart stand-apex locator
OLED type (1.3")
Power supply source for Estus Smart-B smart stand-apex locator
Li-Ro battery (3.7V; 2000mAh)
Weight of the Estus One-B stand
132 year
Overall dimensions of the "Estus One-B" stand
(100*60*40) ±3 mm
Power supply parameters for Estus Energy-S and Estus Smart-B
Input voltage (100-240) V, ~50/60Hz, Output voltage 5V; max. 2,4?
Weight of the Estus Energy-S charging station
130 year
Overall dimensions of the charging station "Estus Energy-S"
(87*56*49) ±3 mm
Integrated radio module NF-03 (in Estus Drive and Estus Smart-B)
2.4-2.525 GHz, max. output power - +7 dBm, range - up to 3 m in line of sight
Protection against electric shock for Estus Drive and Estus Smart-B
Product with internal power supply. Working part type BF
Weight of the Estus Drive handpiece
140 year
Dimensions of the Estus Drive handpiece
(210*33*51) ±3 mm
Max. time to fully charge the 4V battery pack from mains supply
1.5
Max. time to fully charge the 8V battery pack from the charging station
3
Operating time of Estus Drive and Estus Smart-B in standby mode until automatic power off
10
Average continuous operating time of the Estus Drive with a new fully charged battery pack without recharging it
135
Apical stop position adjustment range (when Estus Drive is used in conjunction with Estus Multi, Estus Smart-B or Estus USB)
0.1...1 mm
Measuring range of the integrated apex locator (when Estus Drive is combined with Estus Multi, Estus Smart-B)
3...0 mm
Measuring range of the integrated apex locator (in Estus Drive standalone mode)
2...0 mm
Clockwise/counterclockwise rotation angle in file reciprocal rotation mode (when Estus Drive is working together with Estus Mult
10...360
Counterclockwise rotation angle in file reciprocal rotation mode (in Estus Drive standalone operation mode)
150
Clockwise rotation angle in file reciprocal rotation mode (in Estus Drive standalone operation mode)
30
Limit torque in continuous file rotation mode (when Estus Drive is combined with Estus Multi, Estus Smart-B or Estus
0.2 - 5.1 Ncm
Torque limit in continuous file rotation mode (in Estus Drive stand-alone operation mode)
3.0, 2.0, 1.2, 1.0 Ncm
Accuracy of file rotation speed stabilization
10 %
Speed in continuous file rotation mode (when Estus Drive works together with Estus Multi, Estus Smart-B or Estus USB)
200...1200
Speed in continuous file rotation mode (in Estus Drive standalone operation mode)
500
Estus Drive handpiece power supply
1. Li-Ro battery pack (2x3.7V; 800mAh) with charging station or 2. Li-Ro battery pack (3.7V; 800mAh) with mains charging via Type-C connector
Safety torque reversal (STR) function
STR when torque limit is reached in continuous rotation mode of Ni-Ti files
5 work programs
P1-P4 - continuous rotation, P5 - reciprocal rotation
