Automatic Check Valve ATK.494284.001 for Pipeline Protection

Reverse Flow Valves

Manufacturer: ATEK OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Return valve refers to the protective pipeline fittings, designed for automatic shut-off of the reverse flow of the working medium in pipelines. The valve is steel axisymmetric. The valve is controlled by the working medium flow.

The tightness of the valve gate is class C according to GOST 9544. The valve is hermetically sealed in relation to the external environment. Connection to pipelines is welded.

Welding is carried out by means of adapters on mating flanges. The presence of mating flanges with adapters, which are elements of the design, provides quick removal of the valve without cutting from the pipelines.

Specifications

Type of product according to PP RF 616

Control valves, return valves, safety valves, distribution and mixing valves, separating valves, combined valves, reducing valves

Direction of the environment

By the arrow

Operating medium

Fuel oil, diesel fuel, steam, water

Temperature, up to

400 °C

Nominal pressure, up to

4 MPa

Nominal diameter

125 mm
