Autonomous OSA S1PL Audio Recorder for Passenger-Cashier System

Autonomous Audio Recorder OSA S1PL for Seamless Passenger-Cashier Communication

Manufacturer:UNSO LLC
Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

Autonomous audio recorder OSA S1PL is used for autonomous, without the participation of the operator, audio recording from the intercom Passenger-Cashier, through the glass partitions with automatic recording of conversations on a memory tap with subsequent upload to FTP server.The possibility of choosing the type of intercoms and recording system allows you to form a set for different tasks and budget.Audio recorder is made in the form of a separate board for installation inside the intercom DD-205T-HF, it can not be disconnected, it will record everything.Possibility of selecting the type of intercoms and recording system allows you to form a set for different tasks and budget.Audio recorder is made in the form of a separate board for installation inside the intercom DD-205T-HF, it can not be disconnected, it will record everything.Possibility of selecting the type of intercoms and recording system for different tasks.

Specifications

Acoustic range
10 m
Number of channels
1 pcs
Type of sound source
Intercom DD-205T-HF, DD-215T-HF
Connecting an audio source
Soldering to board pins
Network interface
Ethernet, 100MBit
Device power supply
9...15 V
Current consumption
In sleep mode up to 270 µA; in write mode up to 20 mA
Execution
In the form of a board for installation inside the intercom system
Operating temperature range
0...70 °C
Place of storage of records
Memory card, FTP server
Memory card type
SD HC and XC standards, Class 10
Supported memory card capacity
16...512
Hot swap memory card
Allowed without loss of information
Upload to FTP
Scheduled, at the end of file recording
Connecting to the device
Over Ethernet, RJ45 connector
Protocol used
TCP, HTTP
Differentiation of access rights
Administrator - full rights.
Name of the software package to be used
R-Monitor (under Windows 7, 8, 10)
Interface
Russian-speaking
Recording Modes
Constant, scheduled, acousto-powered
Remote monitoring
Possible online via network and Internet
Recording AGC adjustment range/step
0...45
Recording AGC time constant
0.1...6
An algorithm for compressing audio information:
Without compression. RSM 16 bits, mono
Dynamic range of the recording channel
96
Non-uniformity of the amplitude-frequency response
1.6...1.8
Nonlinear distortion factor
0.8...0.95 %
Signal-to-noise ratio
80
Sampling frequency
16
Operating frequency range
100...7200

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
