Control Cables KUPVng(A)-LS for Low Power Signal Transmission

Available for Import

Control Cables KUPVng(A)-LS for Efficient Low Power Signal Management

Control System Cables

Manufacturer: Podolsk Cable OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

Control Cables KUPEVng(A)-LS-XL

Description

Control cables designed for transmission of electric control signals of low power in control, monitoring and signalling circuits of fixed installation, operating at rated voltage up to 250 V inclusive of AC frequency up to 1000 Hz or up to 350 V inclusive of DC. Cable service life is not less than 30 years at operation in the temperature range from minus 50 to +60°?. Cables with index "XL" from minus 60 to +60°C

Specifications

Insulation material

wrapping with fire-resistant tape

Core material

copper multi-wire (class 4 according to GOST 22483)

Twisting

insulated conductors or pairs of conductors of cables are twisted into a core

Winding

polyethylene terephthalate tape

Separation layer

sheathing material

Screen

copper wire braiding

Cladding

PVC plasticate with reduced flammability

Section

0.35 to 2.50 mm²

Number of cores

3 to 61

Number of pairs

2 to 52

Fire hazard class

according to GOST 31565-2012: P1b.8.2.2.2.2.

Climatic version

B and XL, placement categories 2-5 according to GOST 15150-69

Application

Designed for single or group laying, taking into account the volume of combustible load cables, in internal electrical installations, as well as in buildings, rooms, structures and closed cable structures, including residential and public buildings.

Nominal voltage

250 ?

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
