Flanged Cast Iron Disc Valve with Gearbox DN 250 PN 1.0 MPa IUCL.494465.040

Available for Import

Flanged Cast Iron Disc Valve with Gearbox DN 250 for Marine Applications

Special Purpose Equipment

Manufacturer: ARMALIT OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Designed for ship systems as a locking device for ship and watercraft systems

Specifications

Nominal diameter

250 mm

Nominal pressure

1 MPa

Test pressure

1.5 MPa

Conducted environment

VM-seawater

Conducted medium temperature

0°C to plus 50°C

Material

Cast iron

Pipeline connection type

Flanged

Sealing of the locking body

Metal rubber

Type of control

By means of the handwheel mounted on the gearbox
