High-Performance CNC Lathe NT250C05F3 for Precision Machining Applications

The NT250 lathe machining centre combines high-speed machining capabilities, high positioning accuracy and repeatability, and high torque. -All of these features expand the machine's technological capabilities, allowing for greater flexibility in the way tasks are performed. The rigid, solid cast iron bed guarantees long-term stability of the machine's geometric accuracy. The bed is tilted at 30° to ensure compact dimensions and facilitate chip evacuation. -All linear axes of the machine are equipped with backlash-free roller guideways, which guarantee static and dynamic rigidity for a long service life. -Torque transmission from the main motor to the spindle is carried out through a 2-position backlash-free planetary gearbox Baruffaldi (Italy) and poly-V-belt transmission.
