Hinged Plow for Soil Tillage PLN-8-35PV - Ideal for Deep Plowing
Manufacturer:NEW TON LLC
Price:Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Available Models
Description
The mounted plough PLN-8-35PV is designed for ploughing various soils for grain and technical crops to a depth of up to 30 cm, not clogged with stones, flagstones and other obstacles, with specific resistance up to 0,09 MPa (0,09 kg/cm2) under the following conditions:
- moisture content of the treated layer up to 30 per cent;
- soil hardness up to 4 MPa;
- height (length) of plant and crop residues up to 25 cm;
- maximum field relief slope of 8 degrees.
It is completed with skimmers.
- moisture content of the treated layer up to 30 per cent;
- soil hardness up to 4 MPa;
- height (length) of plant and crop residues up to 25 cm;
- maximum field relief slope of 8 degrees.
It is completed with skimmers.
Specifications
Type of product according to PP RF 616
General purpose plows
Assignment
general
Type
plowshare
Housing working width
Built-in memory card slot, support microSD/SDHC/SDXC card (up to 256GB); manual recording/alarm recording cm
Performance
2.7
Capacity per shift, m3/shift
64800
Overall dimensions in working position of the plow
3650 mm
Overall dimensions (DxWxH), mm
6550x3650x1610
Design working width
2.8 m
Number of enclosures
8 pcs
Depth of treatment
30 cm
Type of aggregation
hinged
Additional equipment - skimmers
8 pcs
Distance from the support plane to the lower plane of the frame
620 mm
Distance between bodies in the plow path
800 mm
Ground clearance in transport position, not less than
210 mm
Weight
1400 kg
Technological wheel
2 pcs
Operating speed at main operations
10
Transport speed
15
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
