Available for ImportHorizontal Boring and Milling Machine STC N 140K for Complex Processing
Manufacturer:ISZ LLC
Price:Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Available Models
Description
Horizontal boring machining centre model STC H 140K with cross-moving stand is designed for complex machining of body and base large-sized parts, including welded, made of ferrous and non-ferrous metals.
The machine with high dynamic characteristics (spindle speed Ø 130 mm up to 3000 rpm, speeds of fast movements up to 15 m/min) and reduction of machine weight to a level sufficient for cost-effective machining of parts.
The machine with high dynamic characteristics (spindle speed Ø 130 mm up to 3000 rpm, speeds of fast movements up to 15 m/min) and reduction of machine weight to a level sufficient for cost-effective machining of parts.
Specifications
Type of product according to PP RF 616
5-axis horizontal machining centers
Length
8000 mm
Width
6000 mm
Height
5200 mm
Machine type
Machining centre STC H 140K
Table work surface size
1250x1400; 1600x1800* 1800x2500; 2000x2500; 2900x3500 mm
Diameter of boring spindle
110; 130*; 150; 160 mm
Maximum spindle speed
1700; 2000; 2500*; 3000
Rated power of the spindle rotation drive
22; 28*; 39 kW
Maximum spindle torque, Nm:
1700; 2050*; 55001700; 2050*; 3500- milling - retractable nm
Maximum programmable movements
- in x-axis (table transversely) 3000; 4000*; 6000; 8000; 12000 and more - in y-axis (spindle headstock vertically) 2000; 2500*; 3000; 3500; 4000; 4500 - in z-axis (boring spindle) 710*; 1000 mm
Maximum programmable movements
- along the w axis (stand longitudinally) 1150; 1600*; 2000 - along the c axis (rotary table); deg 360 mm
Speed of fast movements in X, Y, Z, W axes
m/min 12 m
Maximum feed force in X/ Y/ Z/ W axes
kN 8 / 10 / 8 / 12
Tool magazine capacity
SBVVBG pcs
Maximum tool diameter
125 mm
Maximum tool length, mm 400
400 mm
Machine weight
25000 kg
Table load capacity, kg
6 000; 12 000*; 40 000 kg
Working feed rate limits in X, Y, Z, W axes
mm/min 5 .... 6000 mm
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
