Intrinsically Safe Communication Power Supply SHIP-K Model: SHIP-K-1500/12.1500/12.0000/00

Available for Import

Intrinsically Safe Communication Power Supply SHIP-K for Enhanced Safety in Hazardous Areas

Computer Power Devices

Manufacturer: INGORTECH LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The intrinsically safe power supply communication SHIP-K (Model: Intrinsically safe source SHIP-K-1500/12.1500/12.0000/00) is designed to organise subsystems of intrinsically safe power supply of devices of the System of gas analytical mine multifunctional Mikon III and other intrinsically safe equipment in normal and emergency modes, including in hazardous areas in accordance with Ex-marking. Intrinsically safe power supply communication SHIP-K (Model: Source intrinsically safe SHIP-K-1500/12.1500/12.0000/00) provides the following functions:- Formation of intrinsically safe stabilised DC voltage;- Automatic input of reserve on input voltage when powered from AC network;- Control and telecontrol of main and reserve power supply, channels of intrinsically safe DC power supply, built-in battery, telecontrol of power outputs.

Specifications

Rated capacity of the battery pack, W h

600

Input AC mains supply voltage

32...142 V

Automatic input of standby mains power supply

Got it

Rated DC voltage on the intrinsically safe power output channel

B1/B8 2100/900 MHz V

Maximum current load in rated mode on intrinsically safe output power supply channel, mA

1000

Number of intrinsically safe output power channels

2 pcs

Monitoring of parameters of intrinsically safe output power channels

Got it

Type of battery installed

LiFePO4

Monitoring of battery parameters

Got it

Intrinsically safe interface / tele-alarm, telecontrol protocol

ANSI TIA/EIA-485-A / ModbusRTU

Overall dimensions, not more, mm

500x350x320

Weight

37 kg

Average MTBF

15000

Average and ultimate service life, years

5, 10

Degree of protection against external influences according to GOST 14254, not worse

IP54

Explosion protection level and type (GOST 31610.0)

RV Ex db ma [ia Ma] I Mb X / RO Ex ma [ia Ma] I Ma X

Explosion protection certificate

EAEC NO. RU C-RU.AA87.V00435/20

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
