Low-Flame PVC Insulated Power Cable VVGng(A) Available for Import

Low-Flame PVC Insulated Power Cable VVGng(A) for Safe Power Distribution

High Voltage Power Cables
Manufacturer: EM-KABEL LLC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Available Models

Cable VVG Cable VVGng(A)-LS Cable AVVGng(A) Cable AVVG Cable VVG-XL

Description

Power cable with copper conductors, with insulation made of polyvinyl chloride plasticate, outer sheath made of polyvinyl chloride plasticate of reduced flammability. Cables are intended for transmission and distribution of electric energy in stationary installations at rated voltage of 6kV with rated frequency of 50Hz.

Specifications

Rated AC voltage
6 kV
Material of conductive cores
Copper
Insulation material of conductive cores
polyvinyl chloride plasticate
Availability of reservations
No reservations.
Outer sheath material
polyvinylchloride plastic of reduced flammability
Fire hazard
P1b.8.2.5.4.
Design of conductor core(s)
circular or sectoral
Nominal cross-section of conductive cores
16...800 mm²
Number of conductive cores
3
Mark
VVGng(A)
Number of cores
3 pcs

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
