MCS101-CPU-5R2F Network Controller for Fiber Optic Segments and RS-485 Applications
Manufacturer:
SPBEX-MINING LLC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Available Models
Description
MCS101-CPU-5R2F is a control component of network fibre segments and RS-485 fieldbuses with application software.
Specifications
Assigned service life
10 years
Protection class against electric shock
III
Degree of protection against external influences
IP20
Operating temperature
-20...40 °C
Explosion protection marking
Ex ia op is I Ma U*
Programming system
CODESYS V3.5 SP17
Connectors
Power connector: 2-pole terminal block; RS-485 connector: 2-pole terminal block - 4 pcs, 1-pole terminal block - 2 pcs; optical connector: LC connectors
Data transfer rate
RS-485: 38,400 bps (default); 100BASE-FX: 100 Mbps
Rated DC voltage
B1/B8 2100/900 MHz V
Power consumption, max.
3 W
Standards
IEEE802.3u 100Base-FX, RS-485
Number of RS485 ports (lines):
5 pcs
Number of 100BASE-FX ports (lines):
2 pcs
Management
MODBUS RTU, UDP. TCP
Overall dimensions
153 x 126 x 34 mm
Weight, not more
0.4 kg
Mounting
DIN rail: W-type, width 35mm, recommended height 7.5mm/15mm
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
