Available for Import

Precipitation Sensor DO-04 for Accurate Rain and Snow Measurement

Weather and Measurement Instruments

Manufacturer: MINIMAX-94 OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Precipitation sensor DO-04 is designed to register hydrometeors - particles of atmospheric precipitation falling in the form of rain and snow, hail, wet snow, ice rain. The sensor can be used as independent equipment, as well as to work as part of weather stations, weather stations, automated road weather stations or in systems that monitor the environment.

Specifications

Dimensions (HxWxH), mm

463x321x321

Dimensions with fixing (HxWxH), mm

550x321x321

Weight, max.

1.5 kg

Materials

Aluminium alloy, stainless steel

Mounting

On traverse, bracket or mast

DC source

10 ÷ 30 V, short-circuit and reverse polarity protection

Power over Ethernet (PoE)

IEEE 802.3af standard

Power consumption, max.

21 W

Power consumption basic, not more

3 W

Heating power consumption, not more than

18 W

Communication interfaces

Ethernet 10/100BASE-TX, RS-485

Measurement principle

Optical disdrometer is a device for analysing the volumetric distribution of microparticles in a controlled medium. It allows measuring the number and size of hydrometeors flying through the optical path.

Transmitter modulation frequency

Service life of transmitter

20000

Additional features

Control of radiation intensity; control of contamination and blocking of optical path

Precipitation intensity measurement range

from 0 mm/h

Resolution of rainfall intensity

0,01 mm/h

Precipitation intensity measurement error

±(0.1 + 0.05 x Iism), where Iism is the measured value

Measuring range of precipitation amount

from 0 mm

Resolution of precipitation amounts.

0.01 mm

Precipitation quantity measurement error

±(0.1 + 0.05 x Sizm), where Sizm is the measured value

Types of recorded precipitation

drizzle, rain, snow, sleet, snow with rain, snow flurries, freezing rain, hail

Accumulation time

Ambient air temperature

-50 ... +60 ?

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
