Safety Valve for Liquefied Gases, GT7-172238Available for Import

Safety Valve for Liquefied Gases, GT7-172238 - Automatic Vapor Release and Protection

Safety Relief Equipment
Manufacturer:NGMA LLC
Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

Safety valve is designed for automatic release of vapours of liquefied hydrocarbon gases, anhydrous liquefied ammonia, liquid carbon dioxide from the vessel and pipelines and protection of the vessel and pipelines in case of gas pressure increase above the permitted pressure.

Specifications

Nominal diameter
38 mm
Climatic version
climatic version "U" for temperate climate, placement category 1,2 according to GOST 15150-69. ambient temperature from -40 to +45 0C
Material
20X13 steel
Weight
6.7 kg
Pressure rating
1.57 MPa
