Steam Turbine T-120/130-12.8-NG for Industrial Power Applications

Turbine T-120/130-12,8-NG belongs to class B.1. Turbines of class B.1 are three-cylinder turbines with CVD, CSD and DND. The CFD and DDC of shell design are straight-flow and double-flow DDC are used.

The turbine is a single-shaft three-cylinder unit and is designed to drive a turbogenerator with a speed of 50 s-1, to supply heat for heating and for auxiliary needs of the station from an additional production steam extraction from the bypass pipe of CVD-CSD. The design of the turbine allows to organise the necessary plant heat extraction with heat load up to 143 Gcal/h and heating of network water up to 123 oC. The turbine is a unique development - the secret of production of JSC "UTZ" with patented units and cylinder design.
