Steel Flanged Wedge Gate Valve DN 125 PN 6.4 MPa ITShL.491655.018 Available for Import

Steel Flanged Wedge Gate Valve DN 125 PN 6.4 MPa for Marine Pipeline Systems

Special Purpose Equipment
Manufacturer: ARMALIT OJSC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Available Models

Clinket flanged steel gate valve DN 125 PN 6,4 MPa ITSHL.491655.018

Description

Designed for installation on pipelines of ship systems as a shut-off device

Specifications

Nominal diameter
125 mm
Nominal pressure
6.4 MPa
Test pressure
8 MPa
Conducted environment
П - пар
Conducted medium temperature
Up to plus 470°C
Housing type
Walk-through
Material
Heat-resistant steel
Pipeline connection type
Flanged
Sealing of the locking body
Metal on metal
Type of control
manual
