Steel Wedge Gate Valve with Rising Stem and Manual Handwheel DN 100 mm; PN 1.6 MPa

Available for Import

Steel Wedge Gate Valve with Rising Stem for Pipeline Isolation - DN 100 mm

Gate Valves

Manufacturer:ANKOS LLC

Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

Steel wedge gate valves with sliding spindle with handwheel DN 100 mm; PN 4,0 MPa Steel wedge gate valves with sliding spindle with handwheel DN 100 mm; PN 6,3 MPa Steel wedge gate valves with sliding spindle with handwheel DN 80 mm; PN 1,6 MPa Steel wedge gate valves with sliding spindle with handwheel DN 150 mm; PN 6,3 MPa Steel wedge gate valves with sliding spindle with handwheel DN 80 mm; PN 6,3 MPa

Steel wedge gate valves with sliding spindle with handwheel DN 50 mm; PN 1,6 MPa Steel wedge gate valves with sliding spindle with handwheel DN 50 mm; PN 4,0 MPa Steel wedge gate valves with sliding spindle with handwheel DN 150 mm; PN 1,6 MPa Steel wedge gate valves with sliding spindle with handwheel DN 150 mm; PN 4,0 MPa Steel wedge gate valves with sliding spindle with handwheel DN 50 mm; PN 6,3 MPa Steel wedge gate valves with sliding spindle with handwheel DN 80 mm; PN 4,0 MPa

Description

The gate valves are designed for installation on technological pipelines as shut-off devices. Working medium: natural gas, water, steam, oil, oil products, liquid and gaseous ammonia and other liquid and gaseous media, neutral to the materials of parts in contact with the medium. Ambient air temperature value during storage, transportation, installation and operation of wedge gate valves depending on the climatic version according to GOST 15150.

The direction of supply of the working medium is bilateral. Installation position of the gate valve with handwheel - any, except for the handwheel downwards. Connection to the pipeline is flanged.

Operating position of the locking element - fully open or fully closed.

Specifications

Management

Manual handwheel

Spindle type

Retractable

Hull molding type

Casting

Type of sealing of moving parts against the external environment

Gland seal

Type of seal in the gate

Metal-to-metal

Type of connection to the pipeline

Flanged

Gate valve type

Wedge

Nominal diameter (DN)

100 mm

Nominal pressure (PN), MPa (kgf/cm)

1,6 (16)

Material of construction of the locking mechanism

Wedge all-metal 20?13 or 09G2S with cladding with CN-6L electrode. Seat 09G2S with cladding with CN-6L electrode.

Type of control force transmission from the control element to the gate valve

Handwheel

Main connector type body - cover

flanged

Type of housing flow construction

full bore

Shutter type

Wedge

Maximum torque required to operate the gate valve, no more

450

Flange diameter

215 mm

Construction length

300 mm

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
