Surge Protection Device for Industrial Automation RST 2/6/2 Exi, Cat. No. 404 065

Available for Import

Surge Protection Device for Industrial Automation RST 2/6/2 Exi - Protect Your Equipment

Surge Protection Devices

Manufacturer: HAKEL OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Explosion-proof overvoltage protection devices series ??? 2/*/2 Exi, TU 3428-002-79740390-2007 are designed to protect the equipment of distributed networks of industrial automation equipment (ACS TP, ASKUE, etc.) from impulse overvoltages (lightning protection, protection from electrostatic discharges, etc.) coming from the side of intrinsically safe circuits within 1 - 2 zones of lightning protection in accordance with GOST R IEC 62305-1-2010. Capable of passing the rated discharge current In (8/20)=5 kA, In (10/350)=0,5 kA. They are made in a thin plastic case with a lock for installation on 35 mm DIN-rail.

Specifications

maximum operating current (max.

2 A

Rated operating voltage Un

6 V

Housing material

Polyamide PA6

Weight

68 year

Dimensions, WxWxH

7.4?100?106.4 mm

Explosion protection type marking

0Ex ia IIC T4 Ga X

Provides explosion protection of the type

Intrinsically safe electrical circuit

Number of channels

2 pcs
