Switch Mechanism Type R50 Model 1/5 for 1524 mm Gauge Railways Available for Import

R50 Switch Mechanism for 1524 mm Gauge Railways - Ideal for Metro Park Tracks

Wide Gauge Track Switches
Manufacturer: NSZ OJSC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

Designed for use on park tracks of the underground. Design features: transfers: screw fastening; switches: rotary shank with liner-overlay root fastening; riveted pads with pads; crossbars: one-piece cast from high-manganese steel with rail ends of front and rear outreaches; counter-rail from SP850 corner

Specifications

Cross type by angle
Spicy
View
Single
Type of single transfer
Ordinary
Arrow design
With rotating sharps
Cross brand
1/5
Rail type
?50
View in the direction of a side or crossing track
Left
Cross type by construction
Solid
Type of product according to PP RF 616
Track equipment and devices and their parts
Type of timber
wooden
Save Your Time

Share your requirements for a quick response!

Instant response in 15 minutes
Best wholesale prices guaranteed
Direct from manufacturer

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
