Three-Channel Voltage Meter-Recorder IR-2M "Mendeleevets" for Accurate DC Voltage Measurement
Manufacturer:
CHIMSERVICE CJSC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
Meter-register of voltages three-channel IR-2M "Mendeleevets" is designed for measurement and registration of DC voltage.
The recorder provides: measurement of DC voltage; periodic recording with programmable frequency of measured voltages into internal non-volatile memory; information exchange via Bluetooth wireless network for display of measured voltages and registration settings; transfer of recorded data from internal non-volatile memory to a personal computer via USB interface.
The recorder provides: measurement of DC voltage; periodic recording with programmable frequency of measured voltages into internal non-volatile memory; information exchange via Bluetooth wireless network for display of measured voltages and registration settings; transfer of recorded data from internal non-volatile memory to a personal computer via USB interface.
Specifications
Voltage
-100...100 V
Weight, not more
0.3 kg
Service life, at least
5 year
Completeness
Meter-register of voltages three-channel IR-2M "Mendeleevets"; set of accessories; operation manual.
Dimensions (DxWxH), mm
140x80x30
Number of measurement channels
3 pcs
DC voltage measurement ranges (channels 1-3)
-100...100 V
Level of suppression of industrial noise with frequency of 50 and 100 Hz, not less than
40
Input impedance, not less (by channels: channel 1, limit ±100; channel 1, limits ±1 V and ±10 V; channel 2, all limits; channel
400000000 ohm
Limits of permissible basic absolute error of measurements
+-(0.001*U + 4*k); +-(0.001*U'+ 4*k), where U - dc voltage value, V; U' - dc voltage value, mV; k - lowest digit unit, V (mV)
Installable non-volatile memory capacity, not less than
16
Instrument power supply type
Встроенный литий полимерный аккумулятор
Operating time without recharging from the battery, not less than
48
PC communication interface
USB
Operating temperature
-20...55 °C
Degree of protection against external influences
IP65 according to GOST 14254
Digit capacity of the measuring scale
0.01
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
