Wall-Mounted Laboratory Table 1200x600mm for Efficient Workspace Use

Size 1200h600h900mm .Metal frame welded collapsible1190h570h865mm made of pipe 30h30h1,5mm and sheet 1.0mm and 0.7mm. It consists of a sidewall, upper frame, lower frame and front screen (tsarga).MK utanovlenolevaetsya on the supports diameter of 32mm. Dimensions of the side support are 570x30x865mm.

The sidewall is welded. In the blanks (upper and lower horizontal binders) with dimensions 510h30h30mm made 2 through holes with a diameter of 7mm. A 0.7mm thick metal box with 5 bends around the perimeter is inserted into the support.

Overall dimensions of the box are 717x510x30mm. Dimensions of the upper frame 1130x570x30mm. Dimensions of the bottom frame 1130x570x30mm.In the centre of the frame inserted metal box thickness 0.7mm 20mm around the perimeter (bottom).

Dimensions of one door 775x580mm. The doors are made of 0.7mm thick metal. The doors have metal hinges and handle railing with dimensions 370*30, diameter 10mm with intercentre distance 320mm.

The table top is LDFP 22mm. Bottom and top covered with plastic.
