Waste Product Refrigerator 1200XPG-1.6-M*/25G-6.3-K-2-UHL1-I for Coking Process

The refrigerator of utilisation products 1200???-1,6-?/25?-6,3-?-2-???1-? is designed for utilisation of coking products. Refrigerator of utilisation products 1200KHPG-1,6-M/25G-6,3-K-2-UHL1-I - Refrigerator with a floating head, horizontal, with a casing with diameter - 1200; for conditional pressure in pipes and casing - 1,6 MPa; execution by material M: heat-exchange pipes - 08?18?10?, the rest -12?18?10?, supports - 09G2S; with smooth heat-exchange pipes with diameter - 25, length - 6,3 m, with pipes arrangement in the pipe board on a square; 2-way on a pipe space; place of installation in moderately cold climate - climatic execution 1, with details for fastening of thermal insulation.
