Available for Import
Full-Port Flanged Ball Valve ALSO Stainless Steel for Heating Systems
Manufacturer:
ALSO LLC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Available Models
Stainless steel ALSO stainless steel FLANZED ball valve with all-welded body BUILDING LENGTH OF VALVE KSH.F.Z.125.16-03
Stainless steel ALSO Flanged stainless steel ball valve with all-welded body IN BUILDING LENGTH KSh.F.Z.125.25-03
Stainless steel ALSO Flanged ball valve with all-welded body IN BUILDING LENGTH OF THE VALVE KSH.F.Z.200.25-03
ALSO stainless steel FLANZED ball valve with all-welded body IN BUILDING LENGTH KSh.F.Z.200.16-03
Stainless steel ALSO Flanged ball valve with all-welded body IN BUILDING LENGTH OF VALVE KSH.F.Z.150.16-03
Description
ALSO stainless steel ball valves universal series with all-welded body are designed for water external and internal heating networks at a carrier temperature up to 200 ° C, including water in the circuits of heating networks in accordance with the requirements of PTE "Requirements for the quality of network water".
They are also used for installation on pipelines and structures on them, transporting non-aggressive natural gas, liquefied hydrocarbons, petroleum products and other liquid and gaseous media, in relation to which the materials of the valve are corrosion-resistant.
They are also used for installation on pipelines and structures on them, transporting non-aggressive natural gas, liquefied hydrocarbons, petroleum products and other liquid and gaseous media, in relation to which the materials of the valve are corrosion-resistant.
Specifications
Nominal diameter DN (DN)
80
Nominal pressure PN (Ru)
2.5 MPa
Material
Steel
Steel grade
12CR18NI10T
Connection type
Welding/Flange
Shutter type
Char
nominal passage
complete
Share your requirements for a quick response!
Instant response in 15 minutes
Best wholesale prices guaranteed
Direct from manufacturer
Delivery & Payment
Shipping Terms
Delivery Time
Sea freight: 30-60 days (depending on destination)
Air freight: 14-21 days (for urgent orders)
Payment Methods
