R65 Switch Mechanism for Concrete Beams - Efficient Rail Track Switching

Designed for the transfer of rolling stock from one track to another. It is used on the tracks of railway lines with mixed freight and passenger train traffic and speeds of passenger trains on the straight track up to 140 km/hour. Design features: transfers: separate fastening; elastic bar terminals Skl; pads with flanges, with subsequent welding of rail joints in the track by aluminium-thermite method; switches: flexible shackles with welded rail ends elastic bar terminals Skl; welded pads with cushions; U-shaped spring terminals; roller devices; electric drive arrow modular in sleeper version SP-6M type; crossbars: prefabricated with rail whiskers and shortened cast core made of high-manganese steel with rail ends welded to its rear end; counter-rail made of SP850 corner
