R65 Type Switch Mark 1/11 for Railway Tracks Project MSZ.8365.00.000-06/-07 Available for Import

R65 Type Switch Mark 1/11 for Reliable Railway Track Installation

Wide Gauge Track Switches
Manufacturer: MSZ OJSC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

The track crossing of type R65 of mark 1/11 on reinforced concrete bars is designed for laying on railway tracks of 1 and 2 classes. The switch has flexible shackles with welded rails. The counter rail is not connected with the track rail.

All pads have high flanges. The shackles are hardened by HFI. Frame rails, cross rails, rails of the transfer curve made of rails of OT350 or DT350 category.

Fastening of the transfer to the beam with ZBR terminals.

Specifications

Cross type by angle
Spicy
Cross type by construction
With welded rail ends
Type of single transfer
Ordinary
Switching control
Without arrow translation control system
Cross brand
1/11
View in the direction of a side or crossing track
Right
View
Single
Rail type
?65
Type of under-rail base beam for laying connections
Reinforced concrete
Arrow design
With rotating sharps
Type of product according to PP RF 616
Broad gauge switches

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
