Shaft Electric Furnace SShZ 6.6/7 STC for Metal Annealing and Heat Treatment

Electric Resistance Furnaces

Manufacturer: ES TI CROWN LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Electric shaft furnace SSZ 6.6/7 STC Purpose: Tempering, annealing of metals and alloys. Design features: The control system cabinet is included.

The body of the furnace is made of rolled steel sheet. The furnace lid is equipped with a mechanised drive for lifting, and the outlet to the side - manually. The oven is equipped with an air circulation system.

The heaters are located on the side walls. Lining material for walls and lid with low heat accumulation and low thermal inertia. Accelerated heating up of the furnace to operating temperature and low inertia transition from one mode to another.

Service life (without mechanical damage): heaters, not less than 5 years; linings, not less than 10 years. Advantages: Increased energy efficiency and energy saving during operation. Increase of inter-repair period and service life of heaters and lining.

Increase in the yield of finished products.

Specifications

Type of product according to PP RF 616

Electric resistance furnaces

Mark

SSHZ 6.6/7STC

Furnace type

Shaft SSZ 6.6/7

Workspace size (Diameter x Height)

600 x 600 mm

Overall dimensions

1580 ? 1790 ? 2895

Maximum operating temperature

700 °C

Number of heating zones

1 pcs

Heater power

45 kW

Supply mains voltage

380 V

Mains frequency

SBVVBG

Number of phases

3 pcs

Atmosphere in the furnace workspace

air

Furnace operation mode

600 hours per year, continuous-cyclic schedule

Cage weight

650 kg

Type of climatic version of the furnace

UHL 4.1 GOST 15150-69

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
