Tank Car for Transportation of Oil Products, Model 15-9993 for Railroads

Tank wagon for oil products transportation. It is designed for transporting oil products on the main railways of 1520 mm gauge of the Commonwealth member states, Georgia, the Republic of Latvia, the Republic of Lithuania and the Republic of Estonia. The tank wagon consists of: the boiler of the tank wagon with a safety inlet valve installed on it, a hatch-ladder with a transom-type cover, an internal ladder, a drainage device; external ladders and platforms; boiler mounting on the frame; frame; two biaxial bogies 18-9855, type 3 GOST 9246-2013, equipped with a device for removing the pads from the wheels when the brake is released; braking equipment (pneumatic automatic and parking brakes); two autosleepers. The wagon has increased load capacity (73,3 t) compared to analogues with axial load of 23,5 tf, increased capacity (88 m3), modern discharge and filling and safety valves, running gear with improved dynamic qualities, increased o....
