Two-Stage Worm Gear Motor Reducer MCH2-40/63, MCH2-40/80, MCH2-63/100, MCH2-63/125, MCH2-80/125, MCH2-80/160 for Various Machines

Motor-reducers worm two-stage series MCH2 are drives of general purpose of various machines and mechanisms. Conditions of application. Constant and variable load within the rated torque, single direction and reversible; continuous operation (up to 24 hours per day) or with periodic stops; shaft rotation in any direction without preference, input shaft speed up to 1800 rpm; Type I and II atmosphere according to GOST 15150-69 with air dustiness not more than 10 mg/m3; climatic versions - U, T (for categories of placement 1...

.3), UHL and O (for categories of placement 4) according to GOST 15150-69. placement category 4) according to GOST 15150-69 Unit designation: ??2-80/160?1-1,4-12?-11-4-2-?3-?-380, ??? MCH - type, 2 - number of stages, 80 - centre-to-centre distance of I stage, 160 - centre-to-centre distance of II stage, M1 - modernised, 1,4 - output shaft speed, 12 - assembly variant, K - tapered end of the output shaft, 1 1- variant of worm pair arrangement, 4 - arrangement...
