Universal Worm Gear Reducer 1Ч-160 for Machinery Torque and Speed Control

The universal single-stage worm gearbox 1Ch-160 is designed for changing torques and speed of rotation of the shaft. torques and shaft speed as a component in the drives of machines, equipment and mechanisms. mechanisms. Conditions of application of gearboxes: Constant or variable load, single direction or reversible; Operation with periodic stops or continuous operation up to 24 hours a day; Shaft rotation in any direction; Input shaft speed not exceeding 1800 rpm; Atmosphere types I and II according to GOST 15150-69 at air dustiness not more than 10 mg/m3 and climatic versions U, T for placement categories 1-3 and climatic versions UHL and O for categories of placement 4 of GOST 15150-69. Unit designation 1Ch-160-32-51-1-1-KC-1-UZ, where: 1 - serial number of design development; Ch - worm single-stage, universal; 160 - centre-to-centre distance, mm; 16 - transmission ratio; 51 - assembly variant according to GOST 20373; 1 - gearbox mounting variant; 1 - variant of gearbox mounting; 1 - variant of gearbox location...
